Rough-terrain forklifts & telehandlers
XH Lithium Electric Telehandler, 2.5 to 3.5 t
ElectricSale and rental
- Capacity
- 2.5 - 3.5 t
- Specifications by model
- 3 models
The XH series covers 3 electric telehandler models with a capacity of 2,500 to 3,500 kg, powered by a 310 V high-voltage lithium iron phosphate battery with DC fast charging. Built for lifting at height, loading and material reclaim on site, they accept a range of attachments (forks, bucket, clamp, work platform) through a quick-change device. They offer two drive modes (2WD and 4WD) and three steering modes. Available for sale and for rental.
- 310 V high-voltage lithium battery, fast charge from 30% to 80% in 30 minutes
- Permanent magnet synchronous motor: top speed up to 25 km/h, gradeability up to 45%
- Quick attachment change: forks, bucket, clamp, aerial work
- Two drive modes (2WD / 4WD) and three steering modes
Distributed brand : Hangcha
The needs assessment is free and without obligation.
Download the spec sheet (PDF)Specifications by model
| Model | T25-60XHYG | T35-100XHYG | T35-70XHYG |
|---|---|---|---|
| Lifting capacity | |||
| Max.lift capacity(kg) | 2500 kg | 3500 kg | 3500 kg |
| Lift capacity at maximum height(kg) | 2000 kg | 2500 kg | 2500 kg |
| Lift capacity at maximum reach(kg) | 800 kg | 500 kg | 500 kg |
| Max. lifting height(mm) | 5800 mm | 9800 mm | 7300 mm |
| Max. forward reach(mm) | 3310 mm | 7000 mm | 4170 mm |
| Load centre distance(mm) | 500 mm | 500 mm | 500 mm |
| Dimensions and Weight | |||
| Front overhang (A)(mm) | 1000 mm | 1240 mm | 1260 mm |
| Wheelbase (B)(mm) | 2300 mm | 2750 mm | 2750 mm |
| Tread (C)(mm) | 1500 mm | 1850 mm | 1850 mm |
| Overall length (D)(mm) | 3950 mm | 5030 mm | 5050 mm |
| Fork length (E)(mm) | 1070 mm | 1200 mm | 1200 mm |
| Overall height (F)(mm) | 2020 mm | 2350 mm | 2350 mm |
| Overall width (G)(mm) | 1820 mm | 2300 mm | 2300 mm |
| Cabin width (H)(mm) | 810 mm | 940 mm | 940 mm |
| Min. Ground clearance (J)(mm) | 240 mm | 400 mm | 400 mm |
| Tilt-up angle (K1)(°) | 12 ° | 12 ° | 12 ° |
| Tilt-down angle (K2)(°) | 117 ° | 116 ° | 116 ° |
| Min. turning radius (L)(mm) | 3300 mm | 3700 mm | 3700 mm |
| Weight(kg) | 5500 kg | 9600 kg | 9200 kg |
| Wheels | |||
| Tyre type | Vacuum tire | Vacuum tire | Vacuum tire |
| Tyre size | 12-16.5-14PR /2 | 400/80-24 | 400/80-24 |
| Drive wheel x Steering wheel | 4x4 | 4x4 | 4x4 |
| Performance parameters | |||
| Frame leveling Angle(°) | —— | 9 ° | 9 ° |
| Boom lower/raise angle(°) | -2/68 ° | -3.5/62 ° | -3.5/62 ° |
| Boom raising time (no load)(s) | 11 s | 15 s | 15 s |
| Boom lowering time (no load)(s) | 8 s | 10 s | 11 s |
| Extension time (no load)(s) | 9 s | 17 s | 11 s |
| Retract time (no load)(s) | 9 s | 16 s | 13 s |
| Fork backward time (no load)(s) | 4.5 s | 6 s | 6 s |
| Fork forward time (no load)(s) | 4.5 s | 6 s | 6 s |
| Frame leveling time (side to side)(s) | / | 10 s | 10 s |
| Max. travel speed (no load)(km/h) | 25 km/h | 25 km/h | 25 km/h |
| Max. Drawbar pull(N) | 35000 N | 50000 N | 50000 N |
| Gradeability(%) | 45 % | 45 % | 45 % |
| Motor parameters | |||
| Drive motor power(kW) | 30 kW | 45 kW | 45 kW |
| Pump motor power(kW) | 35 kW | 35 kW | 35 kW |
| Power parameters | |||
| System voltage(V) | 310 V | 310 V | 310 V |
| Battery capacity(Ah) | 150 Ah | 173 Ah | 173 Ah |
| Power(kWh) | 46 kWh | 53 kWh | 53 kWh |
| Charger output power 1P220V(kW) | 3 kW | 3 kW | 3 kW |
| Charger output power 3P380V(kW) | 10 kW | 10 kW | 10 kW |
Hangcha manufacturer specifications, given per model and subject to change; final figures are confirmed in your quote.
Highlights
- The first compact telehandler with a 310 V high-voltage lithium battery in the industry, with high-voltage DC fast-charging technology. Charges from 30% to 80% in only 30 minutes.
- With permanent magnet synchronous motor (PMSM) technology, reaches a top speed of 25 km/h, a maximum gradeability of 45%, and industry-leading performance in its class.
- HANGCHA Family-Design exterior, ergonomic cab, intuitive HMI system and premium driving comfort experience.
- Two drive modes: 2WD (two-wheel drive) and 4WD (four-wheel drive).
- Three steering modes: 4-wheel crab steer, 2-wheel front steer, 4-wheel circle steer.
- Convenient charging solutions, two charging methods: DC fast-charging port and 10 kW built-in charger.
- Equipped with a quick-change device, allowing fast replacement of different attachments, enabling fork loading, shovel loading, clamping, aerial work, etc.
- Comfort: cab can be equipped with air conditioning, radio, and USB charging port as options; adjustable suspension seat; full-proportional joystick with smooth coordinated multi-movements (boom luffing and telescoping); 7-inch display with real-time machine status monitoring and integrated intelligent fault diagnosis system.
- Safety: lithium iron phosphate battery pack (high safety and proven reliability); excellent lighting system with high-brightness LED working lights on the cab front/rear and on the boom for night operation; overload monitoring system with real-time dynamic monitoring to prevent overturning and overloading.
- Maintenance: maintenance arm prevents accidental fall of the arm frame during maintenance; wide-angle tilting cover ensures easy maintenance access.
Standard equipment
- Truck: quick-exchange fork carriage
- Truck: load backrest
- Truck: adjustable suspension seat
- Truck: flame-retardant leather seats
- Truck: traction device
- Truck: load moment limiter / overload monitoring device
- Truck: left operable window
- Truck: horn
- Truck: key switch
- Truck: wide-angle L/R rearview mirrors
- Truck: panoramic reversing mirror
- Truck: front wiper with water spray function
- Truck: rear window wiper
- Truck: high and low beam headlights
- Truck: front and rear work lights
- Truck: working light
- Truck: reverse light
- Steering: three steering modes
- Steering: adjustable steering column
- Hydraulic: hydraulic quick coupler
- Hydraulic: tilt cylinder self-locking valve
- Hydraulic: self-locking valve for telescopic oil cylinder
- Hydraulic: lifting cylinder self-locking valve
- Hydraulic: lifting cylinder maintenance arm
- Hydraulic: hydraulic oil filter
- Hydraulic: hydraulic oil air filter
- Hydraulic: hydraulic oil dipstick
- Power: 2WD and 4WD switch function
- Power: three gears
- Transmission: wet brake
- Transmission: limited slip differential
- Transmission: hydraulic power steering
- Control: dual-axis proportional control handle
- Control: emergency stop switch
- Control: parking brake
- Safety: warning light
- Safety: reverse alarm
- Electronics: built-in charger
- Electronics: DC fast-charging port
- Electronics: fault self-diagnosis function
- Electronics: 7-inch color multifunctional display screen
- Electronics: motor temperature display
- Electronics: warning lamp for unfastened seat belt
- Electronics: water cooling system
- Electronics: heater
- Electronics: reading light
- Electronics: radio
- Electronics: USB charge port
Options
- Truck: air conditioner
- Truck: reverse radar
- Truck: rotating amber beacon
- Truck: fire extinguisher in cabin or at rear
- Truck: rear camera + monitor
- Truck: windshield protective frame
- Truck: fire extinguisher
- Truck: foam-filled tire
- Truck: quick-change heavy-duty multi-purpose bucket
- Truck: quick-change soft bale clamp
- Truck: quick-change crane arm
- Truck: forklift arm
- Safety: reverse camera
- Safety: reverse radar
- Accepts various attachments: fork-mounted extendable truss
- Accepts various attachments: fork-mounted working platform
- Accepts various attachments: bucket
- Accepts various attachments: truss boom
- Cover: XH SERIES, HIGH-VOLTAGE TELEHANDLER, with capacity of 2,500 to 3,500 kg.
- Footer: 2025 VERSION 8 / COPYRIGHT 2025/12.
- HANGCHA GROUP CO., LTD. reserves the right to make any changes without notice concerning colors, equipment, or specifications detailed in this brochure, or to discontinue individual models. The colors of trucks delivered may differ slightly from those in brochures.
- HANGCHA trucks conform to the European Safety Requirements (CE).
- Certifications: ISO9001:2015, ISO14001:2015, ISO45001:2018.
- All Electronics-section features are listed as standard on all models (no options marked).
- For the T25-60XHYG, the frame leveling angle is shown as '——' and the frame leveling time (side to side) as '/' (not applicable).
